EKO-STAR-C 30-150W Wall Mounted Lights has a power range of 30-150W, providing bright and uniform lighting effects. Its stylish design and easy installation make it suitable for a variety of lighting needs in homes, offices, commercial places, etc.
| Housing and finish | |
| Housing | High pressure die-casting aluminum |
| Optic | PMMA/PC |
| Lens | Type l/Type ll /Type lll /Type IV/Type V |
| Protector | Super white tempered glass |
| Housing Color | Grey / black (Default), other color (available on request) |
| Protection Level | IP66 |
| Impact Resistance | IK08 |
| Warranty Time | 5 years |
| Operating conditions | |
| Operating Temperature (Ta) | -40℃ up to +55℃ |
| General information | |
| Recommended Installation Height (m) | 3~15 |
| Compliance | CE/CB/ROHS /IP66 /IK08 |
Structure is optimized by advanced FEA technology Well managed temperature rise between internaland external parts . Even thermal distributions . Higher lumen maintenance rate
| Electrical class | Classl EU ( Default), Class ll EU |
| Driver | Inventronics 1 Philips / MeanWell / MOSO / other brands one request |
| Nominal voltage | 120-277V-50-60Hz 220-240V-50-60Hz |
| Power factor (at full load) | >0.95 |
| Surge protection (kV) | 10KV( Default)/ 20KV (avalable on request) |
| Control protocol(s) | 1-10V dimming (Default) 1 Time control/ DALl |
| Control option(s) | Photocell Remote management |
| Available on request | NEMA socket(3/5/7 pins), Photocell, ZHAGA socket, Short cap, 1-10V dimming, DALl Dimming, PIR |
